Katariya Steel is the most adaptable manufacturer, producer, and stockist of Alloy Steel Pipe Fittings, which satisfy every industry standard to the best of our ability. Our organization has chosen ways that encourage speedy deliveries while keeping administrative processes simple and transparent.

We want all of our clients to be satisfied with the money they have committed with us. We have assembled an outstanding team that has worked tirelessly and generously to achieve the company's goals and missions.

Alloy steel is lighter than other metals and can be heat treated to enhance steel hardenability. Alloying compounds do not make steel harder by itself; nevertheless, they increase the depth tow, which renders steel tougher. This treatment enhances the structural characteristics of a whole cross-section of steel and allows for optimum mechanical parameters in bigger regions. These pipe fittings are tested and certified in accordance with EN 10204/3.1.

Alloy Steel Pipe Fittings, Alloy Steel Buttweld Fittings, ASTM A234 Pipe Fittings, Chromium Molybdenum A234 Pipe Fittings, ASTM A234 AS Butt weld Fittings, ASTM A234 Buttweld Fittings, Alloy Steel A234 Pipe Fittings Manufacturer In Mumbai, India.

Mentioned below are a few to be noted Properties and Applications of Alloy Steel Pipe Fittings:

Toughness, high strength, wear resistance, and fatigue resistance is the primary characteristics of alloy-steel pipe fittings. The alloying elements increase the high thermal durability limitation & creep limit greatly. This object's pipe fittings are also resistant to hydrogen oxidation and higher temperatures. These alloy rods are easy to cast into various forms. Because alloy steel is lower than some other metals, these pipe fittings are important in the automotive sector. Alloy steel is effective in dispersing higher thermal conductivity than other materials and is hence commonly employed in machine production units. In the refineries and pharmaceutical industries, these pipe fittings are also widely employed in hydrogen-containing apparatus and elevated temp equipment. Alloy steel is indeed the most often used steel grade for pressure vessels.

Our policies are entirely ethical, which is evident in our open working environment. The Alloy-steel Pipe fittings are available in a variety of characteristics that range in lengths, size, forms, degrees, and so on, depending on the customer's requirements

ANSI B16.9 AS Buttweld Fittings, ASTM A234 Cr-Mo Pipe Fittings, Alloy Steel A234 Seamless Pipe Fittings, Alloy Steel A234 Butt weld Fittings, ASTM A234 Alloy Steel Pipe Fittings, Alloy Steel A234 Buttweld Pipe Fittings Supplier in India.

Specification For Alloy Steel Pipe Fittings

Alloy Steel Pipe Fittings Standard	ASTM A234 / ASME SA234
Alloy Steel Pipe Fittings Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Alloy Steel Pipe Fittings Dimensions Size Range	1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Alloy Steel Pipe Fittings Type	Seamless / Welded / Fabricated
Alloy Steel Pipe Fittings Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Alloy Steel Pipe Fittings Thickness	Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Various Types of Alloy Steel Pipe Fittings Manufacturer

Alloy Steel Pipe Elbow

Alloy Steel Seamless Elbows
Alloy Steel Buttweld Elbows
ASTM A234 AS Buttweld Pipe Elbow
ASME SA234 Alloy Steel Pipe Elbows
Alloy Steel 90 Deg Butt weld Elbow
ANSI B16.9 Cr-Mo Butt weld Elbow
Alloy Steel 180 Deg. Pipe Elbow

Alloy Steel Pipe Tee

ASTM A234 Alloy Steel Seamless Pipe Tee
Alloy Steel Butt Weld Equal Tee
ASME SA234 Alloy Steel Pipe Tee
AS Buttweld Unequal Tee
Alloy Steel Reducing Tees
Chrome Molybdenum Buttweld Pipe Tee
ANSI B16.9 AS Butt weld Tee

Alloy Steel Pipe Cross

ASTM A234 Alloy Steel Seamless Pipe Cross
Alloy Steel Butt Weld Equal Cross
ASME SA234 Alloy Steel Pipe Cross
AS Buttweld Unequal Cross
Alloy Steel Reducing Crosss
Chrome Molybdenum Buttweld Pipe Cross
ANSI B16.9 AS Butt weld Cross

Alloy Steel Reducers

ASTM A234 Alloy Steel Seamless Reducers
Alloy Steel Butt Weld Reducers
ASME SA234 Alloy Steel Pipe Reducers
AS Buttweld Concentric Reducer
Alloy Steel Eccentric Reducer
Chrome Molybdenum Buttweld Pipe Reducers
ANSI B16.9 AS Butt weld Reducers

Alloy Steel Pipe Cap

ASTM A234 Alloy Steel Pipe Cap
Alloy Steel Butt Weld Pipe Cap
ASME SA234 Alloy Steel Pipe Cap
AS Buttweld Pipe End Cap
Alloy Steel End Pipe Cap
Chrome Molybdenum Buttweld Pipe Cap
ANSI B16.9 AS Butt weld Cap
Alloy Steel Butt weld Pipe Cap

Alloy Steel Stub End

ASTM A234 Alloy Steel Stub End
Alloy Steel Butt Weld Stub End
ASME SA234 Alloy Steel Stub End
AS Buttweld Long Stub Ends
Alloy Steel Short Stub Ends
Chrome Molybdenum Stubends
ANSI B16.9 AS Butt weld Stub End
Alloy Steel Butt weld Stub Ends

Ready Stock Of Alloy Steel Pipe Fittings Supplier

ASTM A234 Alloy Steel Lateral Tee
AS 90° Seamless Elbow
Alloy Steel Buttweld Equal Cross
AS 180° LR Return Bends
Alloy Steel 10D Elbow
Alloy Steel Butt Weld 1.5d Elbow
Alloy Steel Lap Joint Stub Ends
ASME B16.9 Alloy Steel Pipe Nipple

Alloy Steel SR Elbow
Crmo Reducing Tee
Alloy Steel Seamless Pipe Fittings
Alloy Steel Long Rarius Elbow
Alloy Steel Industrial Pipe Fittings
Chrome Moly Steel Swage Nipple
Alloy Steel End Pipe Cap
Chrome Moly Short Radius Elbow

Alloy Steel Pipe Fittings Dimensional Tolerances

**⁽¹⁾ Out-of-round is the sum of absolute values of plus and minus tolerance.**

⁽²⁾ The inside diameter at ends and the nominal wall thicknesses are to be specified by the purchaser.

**IN ACCORDANCE WITH ASME B16.9 – B16.28**
All Fittings				90°and 45° Ells and Tees	Reducers and Lap Joint Stub	Caps	180° Returns			Angularity Tol
Nominal Pipe Plane Size (NPS)	Outside⁽¹⁾ Diameter at Bevel	Inside⁽¹⁾ Diameter at End	Wall⁽²⁾ Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	±1/32	Not less than 87-1/2% of Normal Thickness	±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	10 to 12	3/32	3/16
4	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	±1/16		±1/16	±1/16	±1/4	±1/4	±1/4	±1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	±1/8		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	±3/32		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16
	-3/32
